Specification :
OBSBOT Tail Air
Working State:69.65*73.25*132.5mm
Off State:69.65*73.25*135.5mm
Weight:344.5g
Integrated AI chip, Trillions of calculations per second
Image sensor:1/1.8'' CMOS
Macro pixel size:2.0μm*2.0μm
Effective pixels:8.4 million
Effective pixel resolution:3856x2176
Lens system:8 Optical Lenses
Zoom range:4X digital zoom
ISO range:100-6400
Exposure value:±3EV
Electronic shutter speed:1/8000 s to the limit of frames per second
Focus:Auto Focus/Manual Focus
Aperture:ƒ/1.8
Equivalent focal length:23mm
White balance:2000K-10000K
Gyroscope:6-axis Gyroscope
Photo resolution:4K, 1080P
Video resolution:4K@30/25/24 fps, 1080@60/50/48/30/25/24 fps
Max video storage bit rate:H264: 100Mbps, H265: 80Mbps
Video format:MJPEG, H264, H265
Gimbal installation:Non-removable
Controllable range:Pan: ±150°; Tilt: -65°~32°
Mechanical range:Pan: ±160°; Tilt: ±90°
Max controllable speed:120°/s
Angle jitter:±0.02°
Audio input:Built-in Two MEMS Microphones
Built-in 3.5mm TRS Connector (AUX)
Support MIC IN/LINE IN
Audio modes:Noise Reduction/Stereo Sound
Audio format:AAC/PCM
Operating frequency:2.4 G/5.8 GHz
Signal transmission range:2.4G 140m, 5.8G 80m
Transmission power:2.4 GHz: <18 dBm?FCC/CE/SRRC/MIC?
5.1 GHz: <15 dBm?FCC/CE/SRRC/MIC?
5.8 GHz: <15 dBm?FCC/CE/SRRC?
Bluetooth protocol:BLE 5.0
Bluetooth operation frequency range:2.400 GHz to 2.4835 GHz
USB:2.0
Input:5V/2A
Quick charge protocol:Don't Support
Charging time:90 Minutes (Power off status)
Operating time:154 minutes
*Tested in a laboratory environment while recording 1080p/30fps video and should be used for reference only
Battery type:Lithium Polymer(Li-po)
Battery capacity:1500mAh
Battery energy:11.4Wh
Battery voltage:7.6V
Gesture Control
Micro SD (Up to 512 GB)
Camera working environment temperature: -10°C-40°C
Battery charging ambient temperature: -10°C-40°C
Battery operating ambient temperature: -10°C-40°C
? Charging will stop when the battery temperature exceeds 45°C.
For example, when connected to an external power supply, if the battery temperature exceeds 45°C, the camera will stop charging and will be powered directly from the external power supply.
