Sony PXW-Z90T 4K HDR XDCAM with Fast Hybrid AF Camcorder
JPC
  jpc@jpckemang.com   021-7180487


Sony

Sony PXW-Z90T 4K HDR XDCAM with Fast Hybrid AF Camcorder

Rp 41.999.000   Rp 37.999.000 Warranty: Resmi 1 Tahun Sony Indonesia
Promo :
  • Discount Rp 2.500.000
  • Promo Sony Rp 1.500.000

Periode :
04 November - 01 Desember 2024

Specification :

  • Single 1" Exmor RS CMOS Sensor
  • UHD 4K (3840 x 2160) up to 30p
  • 4K HDR with Hybrid Log-Gamma (HLG)
  • 3G-SDI Output, 2.4 GHz Live Streaming
  • Phase-Detection Autofocus (AF)
  • Zeiss 12x Optical / 18x Clear Image Zoom
  • Records MPEG-2 HD with Optional License
  • XAVC HD / QFHD Recording
  • S-Log3/S-Gamut3 Imaging Options
  • 2 x SD Card Slots, Relay & Simul Modes




Ingin cicilan 0% ? Silahkan klik :

lazada.co.id tokopedia.com blibli.com shoope.co.id bukalapak.com


Included :

  • 1x Sony PXW-Z90
  • 1x XLR Handle
  • 1x Lens Hood
  • 1x Lens Cap
  • 1x Large Eyecup
  • 1x Accessory Shoe Kit
  • 1x USB Cable
  • 1x Sony NP-FV70A V-Series Battery Pack
  • 1x Sony AC-L200 AC Adapter
  • 1x Power Cord
  • 1x RMT-845 Wireless Remote
  • 1x CR2025 Lithium Battery for Remote
  • 1x Manual Book
  • 1x Kartu Garansi Resmi Sony Indonesia

Disclaimer :  Pabrik dapat sewaktu-waktu mengubah kelengkapan ini, dan mungkin saja menyebabkan perbedaan antara yg tercantum di atas dengan content yg Anda terima sewaktu Anda membelinya.


The Sony PXW-Z90 4K HDR XDCAM camcorder offers phase-detection autofocus (AF) and HDR capabilities in a compact, palm-style body. Suitable for corporate events, broadcast news, and television production, the PXW-Z90 camcorder features a stacked 1" Exmor RS CMOS sensor with UHD 4K (3840 x 2160) resolution, a 12x Zeiss optical zoom, an OLED viewfinder, and 3.5" touchscreen LCD monitor. It can record 4K in XAVC Long at 4:2:0, HD in XAVC Long at 4:2:2 10-bit, as well as MPEG HD at 4:2:2 (requires optional license key). S-Log3/S-Gamut3 functions offer users additional image control. Additional features include built-in 2.4/5 GHz for multiple streaming via RTMP/RTMPS protocols and FTP options.

The PXW-Z90's Fast Hybrid AF uses high-density placement of autofocus points and a newly developed AF algorithm to offer highly accurate focusing and tracking—a boon when shooting UHD 4K, especially for individual operators. In movie recording mode, use the appearance of phase-detection AF frames to monitor your subject's focus. The PXW-Z90's 3.5" touchscreen is used to quickly switch focus among subjects. AF Drive Speed, Tracking Depth Range, and Subject Switching Sensitivity can each be configured to suit different subjects and content styles.

Hybrid Log-Gamma (HLG) enables you to future-proof your output by smoothly integrating your 4K recordings into an HDR workflow without the need for color grading during post-production. Capture images with high-quality contrast and resolution using the PXW-Z90's 12x optical Zeiss zoom, and 18x 4K digital zoom (24x in HD). An integrated ND filter function enables greater exposure and depth-of-field control.

The PXW-Z90 camera supports Sony's Slow and Quick Motion for shooting HD video at variable frame rates, including 120 fps. Recording to a variety of formats, frame rates, and codecs, the camcorder supports 100 Mb/s XAVC Long recording of 4K UHD video at up to 29.97p, and 50 Mb/s capture of HD up to 59.94p. Footage is recorded to two SD memory card slots, either simultaneously to both cards or in relay mode to create a backup. The PXW-Z90's 3G-SDI output offers integration with professional studio environments.

The PXW-Z90 provides external microphone support via two 3-pin XLR audio inputs (line, mic, mic +48V phantom) and a 3.5mm mini input. You can also use the PXW-Z90's built-in microphone to record audio when shooting. For multicamera productions, the PXW-Z90 integrates seamlessly with Sony's MCX-500 live switcher (available separately).

Live Streaming

The camera supports RTMP/RTMPS live streaming protocols. This is included with the camera and as a free upgrade if your camera does not have this functionality. You can stream directly from the camera using Wi-Fi or via Ethernet with optional converters such as the Sony VMC-UAM2 or CBK-NA1. No computer is required for streaming.

Integration

The camera is compatible with Sony's XDCAM air, so you can upload proxy footage to the cloud, and editors can start working with your footage remotely. You can even control the camera from your smartphone or tablet using Sony's free Content Browser Mobile app.

Zeiss T* Lens with 12x Optical Zoom

The PXW-Z90's fixed 12x optical wide-angle zoom with 18x Clear Image Zoom technology in UHD 4K (24x in HD).

Frame Rate Flexibility

Record up to UHD 4K video (3840 x 2160p) at 29.97, 25, and 23.98 fps, in XAVC Long in a choice of 100 Mb/s or 60 Mb/s, or HD at frame rates up to 59.94p.

Slow & Quick Recording

Uses Sony's Slow & Quick Motion for recording 1080p/i60 HD video at 1, 2, 4, 8, 15, 30, 60, and 120 fps.

Multiple-Codec Choice

Record in XAVC Long (UHD 4K), MPEG-4 HD at 4:2:0, XAVC Long (HD) 4:2:2, HD 2.0, or XVAC Proxy at 4:2:0, at a variety of data rates (license key required for some codecs).

Built-In ND Filters

The PXW-Z90 incorporates an ND filter function with Clear, 1/4ND, 1/16ND, and 1/64ND for optimal exposure and depth-of-field control.

1" Exmor RS CMOS Sensor

1.0"-type Exmor RS CMOS sensor with approximately 14.2 million effective pixels provides optimal image quality.

Fast Hybrid Autofocus

Offers highly accurate focusing and tracking, especially useful when shooting sharp UHD 4K footage.

Super Slow Motion

Offers slow-motion recording up to 960 fps.

Media Slots

The PXW-Z90 is equipped with two memory card slots—one for SDHC/SDXC cards only, and one compatible with both SDHC/SDXC and Memory Stick PRO Duo (Mark 2) / Memory Stick PRO-HG Duo cards.

Wi-Fi/NFC

Use the PXW-Z90 camcorder's built-in Wi-Fi capability to send FTP files directly from the camcorder or live stream over Wi-Fi. NFC compatibility allows you to connect compatible devices with one touch.

Video Output

3G-SDI output integrates with professional studio environments.
General
Important Note
PXW-Z90 is available from Sony as two SKUs. PXW-Z90V supports both 5Ghz and 2.4Ghz Wi-Fi. PXW-Z90T supports 2.4GHz Wi-Fi. Availability is determined by country/regional regulations.
Mass
Approx 1020g (with lens hood, eyecup)
Approx. 2 lb 4.0 oz (with lens hood,eyecup)
Approx. 1390g (with lens hood, handle, eyecup, NP-FV70A battery)
Approx. 3lb 1oz (with lens hood, handle, eyecup, NP-FV70A battery)
Dimensions (W x H x D)
121.0mm×104.0mm×274.5mm (With the accessories (lens hood, large eyecup) ,excluding the grip belt and including the projecting parts)
4 7/8 x 4 1/8 x 10 7/8 inches (With the accessories (lens hood, large eyecup) ,excluding the grip belt and including the projecting parts)
130.0 x 181.5 x 287.0 mm (With the accessories (lens hood, large eyecup, XLR handle unit) , excluding the grip belt and including the projecting parts)
5 1/8 x 7 1/4 x 11 3/8 inches (With the accessories (lens hood, large eyecup, XLR handle unit) , excluding the grip belt and including the projecting parts)
Power Requirements
DC In: 8.4V
Battery: 7.4V
Power Consumption
Approx. 6.5 W(while recording with viewfinder and XAVC QFHD 2160/30p 60Mbps)
Approx. 6.9 W (while recording with LCD and XAVC QFHD 2160/30p 60Mbps)
Operating Temperature
0°C to 40°C
32°F to 104°F
Storage Temperature
-20°C to +60°C
-4°F to +140°F
Battery Operating Time
Approx. 140min. with NP-FV70A battery (while recording with LCD, XAVC QFHD 2160/30p, 60Mbps)
Approx. 265 min. with NP-FV70A battery (while playing with LCD, XAVC QFHD 2160/30p, 60Mbps)
Recording Format (Video)
XAVC QFHD : MPEG-4 AVC/H.264 4:2:0 Long profile
XAVC HD : MPEG-4 AVC/H.264 4:2:2 Long profile
XAVC Proxy : MPEG-4 AVC/H.264 4:2:0 Long profile
MPEG HD422 (CBKZ-SLMP required) : MPEG-2 422P@HL 4:2:2 Long profile
MPEG HD420 (CBKZ-SLMP required) : MPEG-2 MP@HL 4:2:0 Long profile
MPEG HD Proxy (CBKZ-SLMP required) : MPEG-4 AVC/H.264 4:2:0 Long profile
AVCHD : MPEG-4 AVC/H.264 AVCHD 2.0 format compatible
Recording Format (Audio)
XAVC QFHD : Linear PCM 2ch, 24bit, 48kHz
XAVC HD : Linear PCM 2ch, 24bit, 48kHz
XAVC Proxy : AAC-LC 2ch?16bit?48kHz
MPEG HD422 (CBKZ-SLMP required) : Linear PCM 2ch, 24bit, 48kHz
MPEG HD420 (CBKZ-SLMP required) : Linear PCM 2ch, 16bit, 48kHz
MPEG HD Proxy (CBKZ-SLMP required) : AAC-LC 2ch?16bit?48kHz
AVCHD : Linear PCM 2ch, 16bit, 48kHz / Dolby Digital 2ch, 16bit, 48kHz
Recording Frame Rate
XAVC QFHD (3840 x 2160) @29.97p, 25p, 23.98p 100Mbps/60Mbps
XAVC HD (1920 x 1080) @59.94p, 50p, 29.97p, 25p, 23.98p, 50Mbps/35Mbps
XAVC HD (1920 x 1080) @59.94i, 50i, 50Mbps/35Mbps/25Mbps
XAVC HD (1280 x 720) @59.94p, 50p, 50Mbps
XAVC Proxy (1280 x 720) @59.94p, 50p, 29.97p, 25p, 23.98p, 9Mbps
XAVC Proxy (640 x 360) @59.94p, 50p, 29.97p, 25p, 23.98p, 3Mbps
MPEG HD422 (1920 x 1080) (CBKZ-SLMP required) @59.94i, 50i, 29.97p, 25p, 23.98p, 50Mbps
MPEG HD422 (1280 x 720) (CBKZ-SLMP required) @59.94p, 50p, 50Mbps
MPEG HD420 (1920 x 1080) @59.94i, 50i, 29.97p, 25p, 23.98p, HQ mode(35Mbps)
MPEG HD420 (1440 x 1080) (CBKZ-SLMP required) @59.94i, 50i, HQ mode(35Mbps)
Recording Frame Rate (Cont.)
MPEG HD420 (1280 x 720) (CBKZ-SLMP required) @59.94p, 50p, HQ mode(35Mbps)
MPEG HD Proxy (1280 x 720) (CBKZ-SLMP required) @59.94p, 50p, 29.97p, 25p, 23.98p, 9Mbps
MPEG HD Proxy (640 x 360) (CBKZ-SLMP required) @59.94p, 50p, 29.97p, 25p, 23.98p 3Mbps
AVCHD (1920 x 1080)@59.94p, 50p, PS mode (28Mbps)
AVCHD (1920 x 1080) @59.94i/50i FX mode (24Mbps) FH mode(17Mbps)
AVCHD (1920 x 1080) @29.97p/25p/23.98p, FX mode (24Mbps)
AVCHD (1440 x 1080)@59.94i, 50i LP mode (5Mbps)
AVCHD (1280 x 720)@59.94p, 50p, HQ mode (9Mbps)
Recording/Playback Time
XAVC QFHD @LPCM 2ch 100 Mbps
Approx. 65 min with 64 GB memory card
XAVC QFHD @LPCM 2ch 60 Mbps
Approx. 100 min with 64 GB memory card
XAVC HD @LPCM 2ch 50 Mbps
Approx. 120 min with 64 GB memory card
XAVC HD @LPCM 2ch 35 Mbps
Approx. 170 min with 64 GB memory card
XAVC HD @LPCM 2ch 25 Mbps
Approx. 220 min with 64 GB memory card
MPEG HD422 (CBKZ-SLMP required) @LPCM 2ch 50 Mbps
Approx. 110 min with 64 GB memory card
MPEG HD420 (CBKZ-SLMP required) @LPCM 2ch HQ Mode
Approx. 170 min with 64 GB memory card
AVCHD @LPCM 2ch PS Mode
Approx. 305 min with 64 GB memory card
AVCHD @LPCM 2ch FX Mode
Approx. 360 min with 64 GB memory card
Recording/Playback Time (cont.)
AVCHD @LPCM 2ch FH Mode
Approx. 495 min with 64 GB memory card
AVCHD @LPCM 2ch HQ Mode
Approx. 880 min with 64 GB memory card
AVCHD @LPCM 2ch LP Mode
Approx. 1540 min with 64 GB memory card
Lens
Lens Mount
Fixed
Zoom Ratio
12x (optical), servo
Focal Length
f=9.3 - 111.6mm
equivalent to f=29.0 - 348.0mm on 35 mm lens(16:9)
equivalent to f=32.8 - 393.6mm on 35mm lens(3:2)
Iris
F2.8 - F4.5
auto/manual selectable
Focus
AF/MF selectable
10 mm to ∞ (Wide)
1000 mm to ∞ (Tele)
Image Stabilizer
ON/OFF selectable, shift lens
Filter Diameter
M62 mm
Camera Section
Imaging Device (Type)
1.0-type (13.2mm x 8.8mm) back-illuminated Exmor RS CMOS sensor
Effective Picture Elements
Approx.14.2M pixels(16:9)/Approx.12.0M pixels(3:2)
Built-in Optical Filters
OFF: Clear, 1: 1/4ND, 2: 1/16ND, 3: 1/64ND
Minimum Illumination
Standard [60i] 3lux(1/60 Shutter Speed, gain 33dB)
Standard [50i] 3lux(1/50 Shutter Speed, gain 33dB)

LowLux [60i] 1.7lux(1/30 Shutter Speed, gain 33dB)
LowLux [50i] 1.7lux(1/25 Shutter Speed, gain 33dB)
Shutter Speed
[60i]: 1/8 - 1/10,000
(1/6 - 1/10,000 when shooting with 24p)
[50i]: 1/6 -1/10,000
Slow & Quick Motion Function
[60i]:2160p:Frame rate selectable 1,2,4,8,15,30fps
[50i]:2160p:Frame rate selectable 1,2,3,6,12,25fps
[60i]:1080p:Frame rate selectable 1,2,4,8,15,30,60,120fps
[50i]:1080p:Frame rate selectable 1,2,3,6,12,25,50,100fps
Super Slow Motion
[60i]1080p:Frame rate selectable 240,480,960fps
[50i]:1080p:Frame rate selectable 250,500,1000fps
White Balance
Preset?Indoor:3200K, Outdoor:5600K±7 steps, Color temparature set range:2300-15000K)
Onepush A, B, Auto selectable
Gain
-3, 0, 3, 6, 9, 12,15, 18, 21, 24, 27, 30, 33 dB, AGC
Gamma Curve
Selectable
Streaming
Protocol
AVC / RTMP / RTMPS
1280x720 at 3Mbps
640x360 at 1Mbps
Input/Output
Audio Input
XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable
Video Output
Integrated into Multi/Micro USB jack?×1?, Composite 1.0Vp-p, 75Ω
Audio Output
Integrated into Multi/Micro USB jack
SDI Output
BNC (x1), 3G/HD/SD
SMPTE 424M/292M/259M standards
USB
Multi/Micro USB jack (x1)
Headphone Output
Stereo mini jack (x1)
Speaker Output
Monaural
DC Input
DC jack
Remote
Integrated into Multi/Micro USB jack
Stereo mini-mini jack (Φ2.5mm)
HDMI Output
Type A (x1)
Monitoring
Viewfinder
1.0cm?0.39 type?OLED
Approx. 2.36M dots
LCD
8.8cm?3.5 type)
Approx. 1.56M dots
Built-in Microphone
Built-in Microphone
Omni-directional stereo electret condenser microphone
Media
Type
Memory Stick Pro Duo™ and SD/SDHC/SDXC compatible x1 SD/SDHC/SDXC x1
Wi-Fi/NFC
Supported format
IEEE 802.11 a/b/g/n/ac
Frequency band
2.4 GHz bandwidth
5.2/5.3/5.6/5.8 GHz bandwidth*

* Depending on country / regional regulation and only on PXW-Z90V SKU.
Security
WEP/WPA-PSK/WPA2-PSK
NFC
NFC Forum Type 3 Tag compliant
Supplied Accessories
Supplied Accessories
XLR handle unit (1)
Lens hood (1)
Lens cap (1)
Large eyecup (1)
Accessory shoe kit (1)
USB cable (1)
Rechargeable battery pack (NP-FV70A) (1)
AC Adaptor (AC-L200D) (1)
Power cord (mains lead) (1)
Wireless Remote Commander (RMT-845) (1)
Lithium battery (CR2025 for the Wireless Remote Commander) (1), Pre-installed to the Wireless Remote Commander
Operating Guide (2)
CD-ROM “Manuals for Solid-State Memory Camcorderr” (1)
Warranty (1)
Notes
*
[60i]: when [60i/50i SEL] is set to 60i
[50i]: when [60i/50i SEL] is set to 50i
