Specification :
Disclaimer : Pabrik dapat sewaktu-waktu mengubah kelengkapan ini, dan mungkin saja menyebabkan perbedaan antara yg tercantum di atas dengan content yg Anda terima sewaktu Anda membelinya.
SIMULTANEOUS PLAYBACK TRACKS: | 2 |
SIMULTANEOUS RECORDING TRACKS: | 2 |
FUNCTIONS: | Lo-cut Filter, Limiter,Test Tone,Slate-Tone,Voice Emphasize |
Filter, Playback Position Skipping, Playback Speed Control, A-B Repeat, Auto REC Level, Marker, Auto-Record, Pre-Record, Self-Timer, Overdubbing | |
RECORDING FORMATS: | WAV: 44.1 kHz/16-bit, 48 kHz/16-bit, 48 kHz/24-bit, 96 |
kHz/24-bit | |
A/D CONVERSION: | 24-bit, 128x oversampling |
D/A CONVERSION: | 24-bit, 128x oversampling |
SIGNAL PROCESSING: | 32-bit |
RECORDING MEDIA: | microSD/microSDHC cards (Class 4 or higher, up to 32 |
GB | |
DISPLAY: | 1.25" monochrome LCD (96 × 64) |
BUILT-IN STEREO MIC: | Unidirectional condenser, 90° XY stereo format |
Gain: -∞ dB to +39 dB | |
Maximum sound pressure level: 120 dB SPL | |
INPUTS: | 1/8" stereo phone jack |
Rated input level: -∞ dB to -39 dBm | |
Input impedance: 2 kΩ | |
Plug-in power supported (2.5 V) | |
BUILT-IN SPEAKER: | Built-in 500 mW mono speaker |
Output impedance: 8 Ω | |
OUTPUTS: | 1/8" stereo phone jack (combined line/headphones) |
Rated output level: 20 mW + 20 mW into 32Ω load | |
Output impedance: 10 kΩ or more | |
USB: | Micro USB port |
Mass storage class operation: USB 2.0 high speed | |
Audio interface operation: 44.1/48kHz sampling rate, 16-bit depth, 2-in/2-out | |
Transfer method: asynchronous | |
POWER REQUIREMENTS: | 2 AAA batteries (alkaline, nickel-metal hydride rechargeable, |
or lithium) | |
AC adapter (ZOOM AD-17): DC 5V/1A | |
USB bus power | |
BATTERY LIFE (ALKALINE BATTERIES): | Approximately 10 hours |
(continuous recording time using built-in mic, 44.1 kHz/16-bit) | |
DIMENSIONS: | 1.9 in (W) x 5.4 in (D) x 1.2 in (H) |
50 mm (W) × 137.5 mm (D) × 32 mm (H) | |
WEIGHT: | 0.13 lbs / 60 g (without batteries) |
