Feiyu Scorp Mini 2 Combo Kit Gimbal Stabilizer Black

Camera Compability (Bluetooth) : Compability Camera Compability (Cable) : Compability Lens Compability : Compability Included: 1x Feiyu Scorp Mini 2 1x Extension rod 1x Tripod 1x Magnetic fill light 1x Storage bag 1x USB-C Charging Cable 1x USB-C to Mini Camera Control Cable 1x USB-C to Multi Camera Control Cable 1x USB-C to TRS3.5 Camera Control Cable 1x USB-C to 2.5mm Camera Control Cable (DC2.5mm) 1x USB-C to TRS2.5 Camera Control Cable 1x USB-C to Micro Camera Control Cable 1x USB-C to USB-C Camera Control Cable 1x USB-C to Lightning Cable 1x Fixed screw for support rod 1x Camera fixed screw 1x Lens holder screw 1x GoPro adapter 1x Lens holder 1x Long thumb screw 1x Allen key 1x Focus motor support rod 1x Fixed plate 1x Slider 1x Quick release plate 1x Smartphone holder

Feiyu SCORP-Mini 2 Handheld Gimbal for Smartphones and Cameras (Black)

Designed for creators looking for a compact, versatile, and feature-packed gimbal that can stabilize and control their GoPro, mirrorless camera, and smartphone, Feiyu provides a compelling all-in-one solution with the SCORP-Mini 2 Handheld Gimbal offered here in black. Building on the first generation SCORP-Mini, the Mini 2 adds powerful features such as an integrated AI tracking module, gesture control for single-person shots, a redesigned quick release system to easily change orientation and cameras, an additional 1/4”-20 thread, and improved tilt and roll ranges to give creators even greater flexibility and control.

Compact, Lightweight, and Versatile

Coming in at only 1.87 lb and standing under a foot, the Mini 2 punches above its size supporting a payload of up to 2.65 lb. The included mounting hardware allows users to attach their smartphone, action camera, compact camera, or mirrorless camera for a nimble yet versatile package. Updated ergonomics include an additional 1/4”-20 thread on the tilt axis for mounting accessories, improved joystick and button sensitivity, and a redesigned Arca-type quick release system that includes a slider, L-shaped bracket, and quick release plate for easy mounting and orientation changes. The familiar 1.3” OLED touchscreen, dual hand grips for normal and low angle shots, and dampened multifunction knob round out this compact but highly capable gimbal.

Built-In AI Tracking and Gesture Control

Triple tap the F1 button on the left side of the touchscreen to turn on the power for the integrated AI module. Power can also be toggled through the touchscreen. Once powered, the indicator light will remain solid red. The light will turn green once AI tracking is active. Long press the F1 button to start or stop tracking.

Alternatively, users can use hand gestures:

With an "OK" hand gesture, users can start or stop AI tracking.
Pointing thumbs in opposite directions, either inward or outward, tells the gimbal to stop tracking and enter standby mode.
An open palm gesture triggers the shutter for photo or video. To stop recording, repeat the gesture again.
A double L-shape gesture sets custom framing.

With built-in AI tracking and gesture control, creators can streamline their workflow by eliminating cumbersome setups, additional personnel, and external applications to achieve their desired shot.

Modes and Functions

Follow Modes

Toggle between follow modes using the mode button by the joystick.

PF, or pan follow mode, is the default tracking mode where only the pan axis follows the movement of the user's hand.
PTF, or pan, tilt, and follow mode, incorporates both the pan and tilt axes to follow the user's hand, but not the roll axis.
FPV mode incorporates all three axes to track the user's hand.
FFW, or flash follow mode, is like FPV mode using all three axes to track but designed for high-speed applications.
Lock mode keeps the direction of the gimbal fixed.

Scenario Functions

Within the scenario submenu, select between different gimbal applications.

The auto-rotation function rotates the camera at a set speed and direction set by the user.
The time-lapse mode can be configured for motion time-lapse, static time-lapse, and hyper-lapse. Motion time-lapse shoots between preset waypoints at configurable intervals. Static time-lapse is for fixed shooting angles, and hyper-lapse is for moving time-lapse photography.
Portrait mode turns the tilt and pan axis 90° counterclockwise for vertical shooting.
Selfie mode turns the camera 180° horizontally.
Track video helps with complex and dynamic shots. Users can set up to 10 waypoints for repeatable and precise motion sequences.
Manual lock allows users to quickly adjust their camera by manually moving it to a desired position, holding it for a half a second, then new tilt and/or pan positions are automatically saved.
Panorama mode shoots a series of interconnecting still images for stitched panoramic photographs.

I/O and Camera Control

Extended Ports

To charge the internal 2500mAh battery, there is a USB-C input below the multifunction knob that supports 18W quick charging, topping up the battery in under two hours. There are two additional USB-C ports on the fixed plate—one for simultaneous camera control and power output and the other serving as an extension port for accessories such as focus motors. For physical mounting, there is a 1/4"-20 thread at the bottom handle to mount the tripod or an extension rod. There is another 1/4"-20 thread at the very top of the fixed plate for more accessories, and a M6 thread for support rods.

Camera Control

When connected over USB-C with compatible cameras, the Mini 2 can control parameters such as record, aperture, shutter, ISO, and more. For wireless control, users can connect select cameras to the Mini 2 over Bluetooth and use the Feiyu SCORP application. When mounting a smartphone, use the Feiyu ON application to wirelessly adjust camera parameters and access additional features. Both applications are available for iOS and Android.

For the most current camera and lens compatibility, please visit the Feiyu Technology website.

Feiyu AI Intelligent Tracking Module for Select Gimbals

Add tracking and remote shutter to your SCORP or Vimble series gimbal with this AI Intelligent Tracking Module from Feiyu. The module attaches to your gimbal via magnetic mount and connects to the interface via an integrated USB-C cable. The sensor is then able to detect motion and gesture control from up to 16.4' away in landscape mode without needing to use the Bluetooth app. Toggle AI tracking modes or remote shutter using various gestures.

Compatibility

Feiyu Vimble 3/3E and Vimble 4/4SE gimbals
Feiyu SCORP Series gimbals

Feiyu Magnetic Fill Light for VB4, 4SE, Vimble 3 & 3E

Shed some light on your subject when using your smartphone gimbal with this Magnetic Fill Light from Feiyu. The light mounts onto the top of your VB4, 4SE, Vimble 3, or Vimble 3E smartphone gimbal using a magnet mount, and it plugs into the accessory port of the gimbal using the integrated USB-C cable for power.

The light features two sliders that adjust the brightness up to 712 lux and the color temperature from 3300 to 5200K. It is very light and portable, so it won't add much weight to your gimbal setup.

Specification

General

Name

Feiyu SCORP Mini 2 3-Axis Handheld Camera Stabilizer

Dimensions

210.1*133.7*296mm (gimbal balancing position)
247.6*59.8*234.8mm (gimbal folded position)

Weight

About 852g/1.87lbs (tripod and other accessories and camera not included)

Payload

About 1200g/2.65lbs (well balanced)

Material of Main Body

Synthetic macromolecular resin, alumninum alloy

Water Proof

Not Waterproof

Gimbal

Stabilization

3-axis Motor

Settings Screen

1.3'' OLED Touchscreen

Controllable Range

Tilt: +137°~-60°
Roll: +40°~-40°
Pan: 360°(unlimited)

Rotatable Range

Tilt: 318°(with limitation)
Roll: 320°(with limitation)
Pan: 360°(unlimited)

Battery

Type

Lithium Cell

Capacity

2500mAh, built-in battery cannot be removed, charge it via the USB-C port

Theoretical Battery Life

10 hours

Operating Voltage

6.8V-8.4V

Operating Temperature

-10°- 45°

Charging Time

<2 hours (using 18W fast charger)

APP

Name

Feiyu SCORP (when mounting Mirrorless/Pocket/Action camera)
Feiyu ON (when mounting Smartphone)

Required Operating System

iOS 9.0 or later
Android 6.0 or later

Follow Mode

PF Mode

Pan follow, only the pan axis follows the movement of user's hand

PTF Mode

Pan and tilt follow, where both the pan and tilt axes follow the movement of user's hand, but roll axis does not

FPV Mode

Pan, tilt and roll follow, where all 3 axes follow the movement of user's hand

Lock Mode

All 3 axes do not follow the movement of user's hand, gimbal keeps the direction of the camera fixed

FFW Mode

Flash follow, where all 3 axes follow the movement of user's hand in high follow speed

Extended Ports

At the bottom of the handle:

1/4 inch thread hole*1, which can mount Tripod;

Below the multifunction knob:

Type-C charging port*1;

In front of slider:

M6 thread hole*1, for installation of focus motor support rod;

In front of fixed plate:

1/4 inch thread hole*1, which can mount third party accessories;

In front of quick release plate:

1/4 inch thread hole*1, for installation of lens holder;

On the top of tilt axis:

1/4 inch thread hole*1, which can mount third party accessories;

In front of tilt axis:

Type-C extension port*1 to connect focus motor and other accessories;
Type-C camera control port*1;

Built-in Tracking Function

Built-in AI tracking module, enabling smart subject tracking and gesture control function without the need for an app or external accessories. Before using the AI tracking function, please turn on the AI Power status(AI indicator turns red) through the gimbal touchscreen or pressing the F1 button three times.

Four gesture controls:
"Spread Palm" - Take a picture or start/stop video recording, AI indicator flashes 3 times
"Thumbs Opposite Direction" - Exit smart tracking, AI indicator turns red
"OK Gesture" - Start smart tracking, AI indicator turns green; Stop smart tracking, AI indicator turns red
"Double L-shaped Gesture" - Customize your composition
After you start composing a picture using the double L-shaped gesture, the indicator light will flash green. When you move to the desired position, raise the gesture again to complete the composition and the indicator will turn solid green. This function is typically used when you want to take a shot centered on the person, but also want to introduce the scenery or scene next to it.
FeiyuTech Scorp Mini 2 Four Gesture Controls

How to Control Camera or Smartphone

While connecting the gimbal and cameras with cable(standard accessories for SONY, CANON, NIKON, Panasonic, etc.) or Bluetooth, users can control picture-taking/recording with shutter button and set aperture, shutter, ISO and other camera parameters (see Camera Compatible List for more details).
After connecting the gimbal to the Feiyu ON App via Bluetooth, the gimbal can directly control Feiyu ON for shooting (If the shutter of original camera and third party camera app can be controlled by volume button, SCORP-Mini 2 can also control it).

Auto Tune Motor Power

Auto Tune operation:
Enter the motor power setting through the touchscreen or Feiyu SCORP/Feiyu ON App, select Auto Tune, and then place the gimbal on the table until the display prompts that calibration is complete. The gimbal will automatically adjust the motor power based on the device you have installed.
*It's a normal phenomenon that gimbal will vibrate slightly while Auto Tune to weigh the installed device. When using a new camera and lens combination or device, it is recommended to Auto Tune the motor power after installing the device and turning on the gimbal.

In the Box

SCORP Mini 2 Kit Version
Mini 2 main body*1, Tripod*1, Smartphone holder*1, GoPro adapter*1,
Camera control cable*7 (USB-C to Micro, USB-C to USB-C, USB-C to TRS2.5, USB-C to Multi, USB-C to DC2.5mm, USB-C to TRS3.5, USB-C to Mini), USB-C to Lightning cable*1, USB 2.0 to USB-C Charging Cable*1,
Fixed plate*1, Slider*1, Quick release plate*1, Lens holder*1, Lens holder screw*1, Long thumb screw*1, Allen key*1, Camera fixed screw*1, Fixed screw for support rod*1, Focus motor support rod*1
Wireless magnetic fill light*1, Carbon fiber 275mm extension rod*1 , Storage bag*1
