Specification :
The new RICOH GR III HDF - High-end digital compact camera - featuring a new, built-in HDF (Highlight Diffusion Filter) to create mellow, diffused expressions in highlighted areas
This camera take the basic benefits of the base model - exceptional image quality, flawless operation and outstanding mobility - and allow the user to activate the newly developed, integrated HDF (Highlight Diffusion Filter) with a single movement, which provides soft, smooth images with diffused light areas in addition to the clear, sharply focussed images of the base models.
The GR III HDF feature the newly developed HDF filter (Highlight Diffusion Filter), which emphasises high highlights and produces soft, smooth images.
*ND filter is not installed and is replaced by HDF
High Image Quality
The legendary GR lens This model is equipped with the legendary GR lens that surpasses all other GR lenses with its amazing optical performance.
Firstly, Approximately 24.24 effective megapixels deliver high image quality, and an anti-aliasing filterless construction delivers high-definition rendering even in the finest details.
*GR IIIx HDF // 1/2000 sec // F6.3 // ISO125 // WB: Fl. - Daylight White, Standard // HDF: ON // Photographer: Shiori Iwakura |  |
Quick Response
High-speed hybrid AFs This high-end digital compact camera has Image plane phase-matching AF delivers high-speed AF and contrast-detection AF offers superb focusing precision. The hybrid system delivers faster autofocus and greater precision.
|  |
Evolving
Expanded functionality firmware for an ever-evolving GR III HDF The GR III HDF keeps evolving with the latest firmware updates. Flexible customization Frequently used functions can be assigned to the ADJ lever and Fn button. Image Control & JPEG image adjustment The GR III HDF features many selections of advanced image creation functions.
*GR IIIx HDF // 1/20 sec // F2.8 // ISO400 // -0.7EV // Color Temperature, Negative Film // HDF: ON // Photographer: Samuel Lintaro Hopf |  |
MODEL DESCRIPTION
Camera-Typ | TTL autofocus, auto-exposure Compact digital-still camera |
|---|
LENS
Focal Lenght | 18.3mm (Approx. 28mm in 35mm equivalent focal length) |
|---|---|
Aperture | F2.8?F16 |
Construction | 6 elements in 4 groups (2 aspherical lens elements) |
IMAGE CAPTURE UNIT
Image Sensor | Type: Primary color filter CMOS. Size: 23.5mm x 15.6mm |
|---|---|
Effective Pixels | Approx. 24.24 megapixels |
| Total Pixels | |
| Sensitivity (Standard output) | ISO100?102400 |
| Image Stabilizer | Sensor-shift shake reduction (SR)(3-axis) |
| AA Filter Simulator | Moiré reduction using SR unit (Off, Low, High) |
| Dust Removal | Image sensor cleaning using ultrasonic vibrations "DR II" |
| File format | RAW (DNG) 14bit, JPEG (Exif 2.3), DCF2.0 compliant |
|---|---|
| Recorded Pixels | ?3:2?L(24M:6000x4000), M(15M:4800x3200), S(7M:3360x2240), XS(2M:1920x1280) |
| Quality Level | RAW (14bit): PEF, DNG |
| Color Space | sRGB, AdobeRGB |
| Storage Medium | Internal Memory (Approx. 2GB), SD/SDHC/SDXC Memory Card (Conforms to UHS-I standards) |
WHITE BALLANCE
Type of White Balance | AUTO WB, Multi Auto WB |
|---|---|
Light temperature - presets | Daylight, Shade, Cloudy, Fluorescent Light (D:Daylight Color, N:Daylight White, W:Cool White, L:Warm White), Tungsten Light, CTE, Manual WB (up to 3 settings), Color Temperature Configuration (up to 3 settings), Copying the white balance setting of a captured image |
Fine Adjustment | Adjustable ±14 steps on A-B axis or G-M axis |
LCD MONITOR
Monitor Type | TFT color LCD, Wide viewing angle, Air-gapless tempered glass |
|---|---|
Touch Screen standard | Capacitive sensing method |
| Size | 3.0 inch (aspect ratio 3:2) |
| Resolution | Approx. 1037K dots |
| Adjustment | Brightness, Saturation and Colors adjustable |
| Display | Display magnification (4x, 16x), Grid display (4x4 Grid, 3x3 Grid), Histogram, Bright area warning, Electronic Level |
AUTOFOCUS SYSTEM
| Type of AF-System | Hybrid AF (Image plane phase-matching and Contrast detection) |
|---|---|
| Focus Mode | Auto-area AF, Zone AF, Select AF, Pinpoint AF, Tracking AF, Continuous AF, MF, Snap (1m, 1.5m, 2m, 2.5m, 5m,∞), ∞ |
| Full Press Snap | Performs shooting by focusing at the Snap distance with a single press of the Shutter Release Button or a touch of the LCD Monitor* *The latest firmware is required to use the full feature with GR III |
| Face/Eye Detection | ON, Use only in Auto-area, OFF |
| Focus Range (From lens face) | Normal: Approx. 0.1m?∞, Macro Mode: Approx. 0.06m?0.12m |
EXPOSURE
| Type of Metering System | Multi-segment, Center-weighted, Spot, Highlight-weighted |
|---|---|
| Exposure Mode | Program AE, Aperture Priority AE, Shutter Priority AE, Manual Exposure |
| EV Compensation | Still Image: ±5EV, 1/3EV steps, Movie: ±2EV, 1/3EV steps |
| HDF (Highlight Diffusion Filter) | ON, OFF |
SHUTTER
| Shutter-Type | Electronically controlled lens shutter |
|---|---|
| Shutter Speed | 1/4000 sec. - 30 sec. (Limit by aperture setting F2.8: 1/2500 sec, F5.6 or greater: 1/4000 sec.) |
DRIVE MODES
| Mode Selection | Single Frame Shooting, Continuous Shooting, Bracketing, Multi-exposure, Interval Shooting, Interval Composite |
|---|---|
| Self-timer | 10 sec., 2 sec., OFF |
| Multi-Exposure | Composite Mode(Additive/Average/Bright) |
EXTERNAL FLASH
| Hot Shoe | Compatible with P-TTL Auto Flash |
|---|---|
| Flash Mode | Flash On, Flash On+Red-eye, Slow-speed Sync, Slow Sync+Red-eye |
| Flash Exposure Compensation: | -2.0 -+1.0 |
SHOOTING FUNCTIONS
| Custom Image / Image Control | Standard, Vivid, Monotone, Soft Monotone, Hard Monotone, Hi-Contrast B&W, Positive Film, Bleach Bypass, Retro, Cross Processing*, HDR Tone, Custom1, Custom2 |
|---|---|
| Digital Filter | For Shooting and Edition Process |
| D-RANGE Compensation | Highlight Correction, Shadow Correction |
| Noise Reduction | Slow Shutter Speed NR, High-ISO NR |
| Horizon Correction | SR On: correction up to 1 degrees, SR Off: correction up to 1.5 degrees |
| Crop | 35mm, 50mm, OFF |
MOVIE
| File Format | MPEG-4 AVC/H.264(MOV |
|---|---|
| Recorded Pixels | Full HD (1920x1080, 60p/30p/24p) |
| Sound | Built-in stereo microphone |
| Recording Time | Up to 25 minutes or 4GB ; automatically stops recording if the internal temperature of the camera becomes high. |
PLAYBACK
| Playback View | Single frame, Multi-image (20, 48 frames), Display magnification (up to 16x, 100% view and Quick Zoom view available), Histogram (Y histogram, RGB histogram), Grid display (3x3 Grid, 4x4 Grid), Bright area warning, Auto Image Rotation |
|---|---|
| Base Parameter Adjustment | Normal editing, Monotone editing* |
| RAW Development | RAW file select: Select Single Image, Select Multiple Images, Select a folder, Select a shooting date Aspect Ratio, JPEG Recorded Pixels, Color Space, White Balance, Image Control, Peripheral Illumination Correction, Sensitivity, High-ISO Noise Reduction, Shadow Correction |
Edit | Delete, Protect, Image Rotation, Image Copy, File Transfer, Resize, Cropping (Aspect ratio and Slant adjustment* available), Levels Adjustment, White Balance Adjustment, Color Moiré Correction, Movie Edit (Cut), Movie Edit (Divide) |
INTERFACES
| USB Connection | USB Type-C™, Battery Recharge/Power Supply (Optional AC Adapter required), Data Transfer: MTP, Video output: DisplayPort over USB-C (DisplayPort Alternative Mode) |
|---|---|
| Lens adapter pin | Available |
WIRELESS LAN
| WLAN Standard | IEEE 802.11b/g/n (HT20) (Wireless LAN standard protocol) |
|---|---|
| Frequency (Center Frequency) | 2412MHz?2462MHz (1ch?11ch) |
| Security | Authentication: WPA2, Encryption: AES |
BLUETOOTH®
| Transfer Protocol | Bluetooth® v4.2 (Bluetooth Low Energy) |
|---|---|
| Frequency (Center Frequency) | 2402MHz?2480MHz(CH0?CH39) |
DIMENSIONS AND WEIGHT
| Dimensions | Approx. 109.4(W)×61.9(H)×33.2(D)mm (excluding protrusions) |
|---|---|
| Weight | Approx. 257g (Including dedicated battery and SD Memory Card), |
POWER SUPPLY
| Battery Type | Rechargeable Lithium-ion Battery DB110 |
|---|---|
| AC Adapter | AC Adapter Kit K-AC166(Optional) |
| Battery Life | Number of recordable images: Approx. 200 images, |
| Battery Charging | by USB Type-C™, Battery Recharge/Power Supply |
INCLUDED ACCESSORIES
Rechargeable lithium-ion battery DB110 - Art No. 37838 |
| Art. No | 1271 |
|---|---|
| Body Color | black |
| Released | April 2024 |
OPTIONAL ACCESSORIES
AC ADAPTER KIT K-AC166E - Art. No. 38371 RECHRGEABLE BATTERY DB-110 - Art. No. 37838 BATTERY CHARGER BJ-11 - Art. No. 37861 RICOH EXTERNAL VIEW FINDER GV-1 W/W - Art. No. 172780 RICOH EXTERNAL VIEW FINDER GV-2 W/W - Art. No. 175090 LENS ADAPTER GA-1 - Art. No. 37817 WIDECONVERSION LENS GW-4 - Art. No. 30248 SOFT CASE GC-9 - Art. No. 30249 SOFT CASE GC-10 - Art. No. 30251 RICOH STRAP ST-2 WW - Art. No. 174790 RICOH STRAP GS-3 WW - Art. No. 175810 RICOH STRAP GS-2 WW - Art. No. 173381 METAL HOTSHOE COVER GK-1 - Art. No. 30252 RING CAP GN-1 (BLACK) - Art. No. 37819 RING CAP GN-1 (DARK GRAY) - Art. No. 37823 RICOH CABLE SWITCH CA-3 - Art. No. 30004 |
SYSTEM REQUIREMENTS
| OS | Windows 10 (FCU/CU)(32bit/64bit) / Windows 8.1 (32bit/64bit) |
|---|
| OS | macOS 11 BigSur, macOS 10.15 Catalina, macOS 10.14 Mojave |
|---|
* The operating system must be pre-installed in the computer, and updated to the latest version.
The system requirements above do not necessarily gurantee proper operation with all computers.
STORAGE CAPACITY
RAW
| Recorded Pixels | 24M(6000 x 4000) |
| SD Card 8 GB | 150 |
| Internal Memory | 40 |
JPEG
| Recorded Pixels | L - 24M(6000 x 4000) |
| SD Card 8 GB | 527 |
| Internal Memory | 140 |
| Recorded Pixels | M - 15M(4800 x 3200) |
| SD Card 8 GB | 820 |
| Internal Memory | 218 |
| Recorded Pixels | S - 7M(3360 x 2240) |
| SD Card 8 GB | 1646 |
| Internal Memory | 437 |
| Recorded Pixels | 2M(1920 x 1280) |
| SD Card 8 GB | 4717 |
| Internal Memory | 1253 |
| Recorded Pixels | Full HD (1920 x 1080) |
|---|
| Time (approx.) | 00:12′17″ | 00:24′09″ | 00:29′56″ |
|---|---|---|---|
| SD Card 8GB | 60p | 30p | 24p |
[Hours : Minutes' Seconds'']
* You can record up to 25 min. or 4GB movie for one shooting.
* ‘Testing your camera’ refers to confirmed operation by RICOH IMAGING, and is intended for customer convenience but is not a guarantee by RICOH IMAGING to the customer.
* Use a high-speed SD memory card when recording movies. If the writing speed cannot keep up with the recording speed, writing may be interrupted during recording.
COPYRIGHT
* The contents of this webpage are all copyrighted, and must not be used, duplicated or transmitted, whether in part or in entirety, without permission.
* Designs and specifications are subject to change without notice.
