Image Sensor
Type
1/2.33'' CMOS
Effective pixels
12 Megapixels
Full resolution
12.7 Megapixels
Filter array
Primary colour filter (RGB)
Lens
Maximum aperture
2.0 - 4.9
Aspherical glass elements
3
Focal length (equiv. 35mm)
25 - 100mm
Focal length
4.5 - 18.0mm
Filter diamater
40.5mm Adapter CLA-T01 required
Optical zoom
4x (WIDE)
Structure
9 lenses / 7 groups
Monitor
Monitor type
LCD
Resolution
1040K dots
Monitor size
7.6cm / 3'' (3:2)
Brightness adjustment
+/- 7 levels
Live View
Available
Focusing System
Method
TTL iESP auto focus with contrast detection
AF illuminator
Equipped
AF lock
Available
Standard mode
0.1m - ∞ (wide) / 0.1m - ∞ (tele)
Super Macro Mode
Closest focusing distance: 1cm
Microscope Mode
Zoom capability while being in Super Macro Mode
Focus Bracketing Mode
----------
Number of images
10 / 20 / 30 shots
Step size
3 levels
Modes
AF Tracking, AREA, Face Detection AF, Spot, Manual focus, Single AF
Focus peaking
----------
Color selection
White, black, red, yellow
Focus Stacking Mode
----------
Technology
Available
Note
Angle of view becomes slightly smaller
Exposure System
Modes
Aperture priority, Programme automatic, Art Filter, Custom shooting, i-Auto, Microscope, Movie, Scene Modes, Underwater
Shutter speed
1/2 - 1/2000s / < 4s (Night scene / A mode)
Exposure compensation
+/- 2 EV / 1/3 steps
Enhancement function
Mechanical Image Stabiliser (Sensor shift)
-----
Advanced Face Detection Technology
-----
Shadow Adjustment Technology
Scene Modes
Number of scene modes
22
Modes
Backlight HDR, Beach and Snow, Candle, Children, Documents, e-Portrait, Fireworks, Hand-held Starlight, Indoor, Landscape, Landscape with Portrait, Live Composite, Night Scene, Night Scene with portrait, Panorama, Portrait, Sports, Sunset, Construction 1/2/3, Slow Shutter
Light Metering
Modes
ESP light metering, Spot metering
Histogram in shooting mode
Available
Art Filter
Modes
Bleach Bypass, Cross Process, Diorama, Dramatic Tone, Gentle Sepia, Grainy Film, Instant Film, Key Line, Light Tone, Pale & Light Colour, Partial Colour*, Pin Hole, Pop Art, Soft Focus, Vintage, Water colour
Note
* 18 colours selectable
Sensitivity
Auto
AUTO
Manual
ISO 100 - 12800
White Balance
AUTO WB system
Applied
Custom WB
1 setting can be registered at Kelvin temperature (2000K - 14000K)
One-touch white balance
4 custom settings can be registered
Preset values
6
Underwater WB presets
3
Sequence Shooting
Speed (H)
Approx. 20fps
-----
Max. number of frames: RAW 46 / JPG: 74
Speed (L)
5fps
-----
Max. number of frames: RAW 115 / JPG: Up to card capacity
Pro Capture mode
----------
Pre-shutter Frames
5 frames
Speed (H)
10fps
Interval shooting
----------
Settings
Time or Frame priority
-----
Max. number of frames: 299 (Creation of time-lapse movie possible)
-----
Exposure smoothing
Image Processing
Noise reduction
Available
Distortion compensation
Available
Engine
TruePic VIII
Pixel mapping
Available
Shading compensation
Available
Flash
Modes
AUTO, Fill-in, Manual, Off, Red-eye reduction
Working range (tele)
0.2 - 3.1m (ISO 1600)
Working range (wide)
0.2 - 7.9m (ISO 1600)
Flash compensation
Available
Wireless Flash Control
Control method
Triggered and controlled (Olympus Wireless RC Flash system)
-----
Commander flash:
Group setting
1 groups
Compatible external flash
FL-600R, FL-700WR, FL-900R
Number of channels
1 channels
Still Image Recording
DCF
2.0
DPOF
Applied
EXIF
2.31
PIM
III
Image Size
Aspect ratio
4:3 / 3:2 / 16:9 / 1:1 / 3:4
Resolution
4000 x 3000 - 640 x 480
RAW
Yes
Movie Recording System
Recording format
MOV(MPEG-4AVC/H.264)
Image Stabilisation Mode
Digital Image Stabilisation
4K Movie quality
3840 x 2160 (4K) / 30p, 25p (approx. 102Mbps)
-----
Recording time: 29min.
HD Movie quality
1080P Recording time: 29min.
-----
720P Recording time: 29min.
Note
Speed Class 10 SD card is recommended for shooting movies. UHS-I Speed Class 3 SD card must be used for 4K video and high speed movie.
Movie Specialties
Art Filter
Bleach Bypass, Cross Process, Diorama, Dramatic Tone, Gentle Sepia, Grainy Film, Instant Film, Key Line, Light Tone, Pale & Light Colour, Partial Colour*, Pin Hole, Pop Art, Soft Focus, Vintage, Water colour
Note
Not available for 4K and High Speed movies
Note
Frame rate may drop when using certain art filter
High-Speed Recording
640 x 360 (SD) / 480fps
-----
720P / 240fps
-----
1080P / 120fps
Note
Max. recording time: 20s
Vertical Video
Available
Time lapse
720p (AVI Motion JPEG®)
Sound Recording System
Sound recording
Available, format: PCM
Speaker
Equipped
Voice Playback
Available
Image footage
4s
Internal microphone
Stereo
View Images
Modes
Event, Index, Single, Slide show, Zoom
Histogram in playback mode
Available
Index
5 x 4 frames
Image protect mode
Available
Zoom
Available 1.1 - 14x
Auto rotation
Available
View Movie
Modes
Fast forward, Frame by frame, Reverse playback, Vertical Video
Image Editing
Editing functions
Aspect ratio, Correction of saturation, e-Portrait, Gradation auto, Monochrome, Image Overlay, Voice Appendage, RAW data edit, Red-eye reduction, Resize, Sepia, Trimming
Movie Editing
In-movie image extraction
Available (4K only)
Trimming
Available
Customisation Options
My Mode
2 settings storable
Menu languages in camera
18
Interface
DC input
Equipped
HDMI™
Applied Micro connector (Type D) *
USB
Type-C
Combined A/V & USB output
Equipped
USB 2.0 High Speed
Applied
Wireless connectivity
Bluetooth®, Wi-Fi
Note
* "HDMI", the HDMI logo and "High-Definition Multimedia Interface" are trademarks or registered trademarks of HDMI Licensing LLC.
Memory
Eye-Fi Card compatible
Applied
Removable Media
SD / SDHC / SDXC (UHS-I class supported)
Other Features
Date imprint
Available
Electronic compass
Applied
GPS
Applied
GPS info function
GPS info function: Via smartphone GPS data
LED Illuminator
Equipped
Level Gauge
Available
Manometer
Applied
Menu guide
Available
Panorama function
In-Camera Panorama
Perfect Shot Preview
Available
Self timer
Delay: 2 / 12s / Custom
SNS upload
Available
Thermometer
Applied
Wireless control
Via OI.Share app
Tough Features
Waterproof
15m (water pressure equivalent to depth) **
Anti-fog
Dual pane glass
Dustproof
Applied ****
Crushproof
100kg
Freezeproof
-10°C
Shock resistant
2.1m (dropping from height)
-----
* Equivalent to MIL Standard (Olympus test conditions)
** According to IEC standard publication 529 IPX8
-----
*** According to Olympus test conditions
-----
**** According to IEC standard publication 529 IPX6
Power Supply
Battery
LI-92B Lithium-Ion Battery
Internal Charging
Available
Dimensions / Weight
Width
113.9mm
Depth
32.7mm
Height
65.8mm
-----
(without protrusions)
Weight
249g (including battery and memory card)
