Specification :
Included :
1x Fujifilm GFX100 II Body Only
1x Interchangeable electronic viewfinder EVF-GFX3
1x Li-ion battery NP-W235
1x AC power adapter AC-5VJ
1x Plug adapter
1x USB cable
1x Shoulder strap
1x Body cap
1x Hot shoe cover
1x Vertical battery grip connector cover
1x Memory card slot cover
1x Sync terminal cover
1x Cooling fan connector cover
1x Cable protector
1x Manual Book
1x Kartu Garansi Resmi Fujifilm Indonesia
| Model name | FUJIFILM GFX100 II | |
| Lens Mount | FUJIFILM G mount | |
| Image sensor | 43.8mm×32.9mm GFX 102MP CMOS II HS with primary color filter | |
| Number of effective pixels | 102 million pixels | |
| Sensor Cleaning System | Ultra Sonic Vibration | |
| Image Processing Engine | X-Processor 5 | |
| Storage media | SD Card (-2GB) / SDHC Card (-32GB) / SDXC Card (-2TB) / UHS-I / UHS-II / Video Speed Class V90 / CFexpress Type B Card (-2TB) / SSD (-2TB) *Please see the Fujifilm website (https://fujifilm-x.com/support/compatibility/cameras/) to check memory card compatibility. | |
| File format of still image | DCF | Compliant with Design rule for Camera File system (DCF2.0) |
| JPEG | Exif Ver.2.32*1 | |
| HEIF | 4:2:2 10bit | |
| RAW | 14bit / 16bit RAW (RAF original format) | |
| TIFF | 8bit / 16bit RGB (In-camera Raw Conversion Only) | |
| Number of recorded pixels | ?L? | ?4:3? 11648 x 8736 ?3:2? 11648 x 7768 ?16:9? 11648 x 6552 ?1:1? 8736 x 8736 ?65:24? 11648 x 4304 ?5:4? 10928 x 8736 ?7:6? 10192 x 8736 |
| ?M? | ?4:3? 8256 x 6192 ?3:2? 8256 x 5504 ?16:9? 8256 x 4640 ?1:1? 6192 x 6192 ?65:24? 8256 x 3048 ?5:4? 7744 x 6192 ?7:6? 7232 x 6192 | |
| ?S? | ?4:3? 4000 x 3000 ?3:2? 4000 x 2664 ?16:9? 4000 x 2248 ?1:1? 2992 x 2992 ?65:24? 4000 x 1480 ?5:4? 3744 x 3000 ?7:6? 3504 x 3000 | |
| Sensitivity | Still Image | Standard Output: AUTO1 / AUTO2 / AUTO3 / ISO80?12800 (1/3 step) Extended Output: ISO40 / ISO25600 / ISO51200 / ISO102400 |
| Movie | Standard Output: AUTO / ISO100?12800 (1/3 step) Extended Output: ISO25600 | |
| Exposure control | TTL 256-zone metering / Multi / Spot / Average / Center Weighted | |
| Exposure mode | P (Program AE) / A (Aperture Priority AE) / S (Shutter Speed Priority AE) / M (Manual Exposure) | |
| Exposure compensation | Still | -5.0EV?+5.0EV?1/3EV step |
| Movie | -2.0EV?+2.0EV 1/3EV step | |
| Image stabilizer | Mechanism | Image sensor shift mechanism with 5-axis compensation |
| Compensation Effect | 8.0 stops *based on CIPA standard *Pitch/yaw shake only *With GF63mmF2.8 R WR lens mounted | |
| Digital Image Stabilization | Yes (movie mode only) | |
| IS MODE BOOST | Yes (movie mode only) | |
| Shutter type | Focal Plane Shutter | |
| Shutter speed | Mechanical shutter | P mode: 30sec. to 1/4000sec. A mode: 30sec. to 1/4000sec. S/M mode: 60min. to 1/4000sec. Bulb: up to 60min. |
| Electronic shutter | P mode: 30sec. to 1/32000sec. A mode: 30sec. to 1/32000sec. S/M mode: 60min. to 1/32000sec. Bulb: up to 60min. *The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash can not be used. | |
| Mechanical + Electronic shutter | P mode: 30sec. to 1/32000sec. A mode: 30sec. to 1/32000sec. S/M mode: 60min. to 1/32000sec. Bulb: up to 60min. *Mechanical shutter works until 1/4000sec. *The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash can not be used. | |
| E-front + Mechanical shutter (GFX: Electronic Front Curtain Shutter) | P mode: 30sec. to 1/4000sec. A mode: 30sec. to 1/4000sec. S/M mode: 60min. to 1/4000sec. Bulb: up to 60min. *Electronic front curtain shutter works until 1/1250sec. *When using the electronic front curtain shutter, the continuous shooting supports CL only | |
| E-front + Mechanical + Electronic shutter (GFX: E-Front + Electronic Shutter) | P mode: 30sec. to 1/32000sec. A mode: 30sec. to 1/32000sec. S/M mode: 60min. to 1/32000sec. Bulb: up to 60min. *Electronic front curtain shutter works until 1/1250sec, Mechanical shutter works until 1/4000sec. *The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash can not be used. *When using the electronic front curtain shutter, the continuous shooting supports CL only | |
| Movie | 8K/DCI8K: 1/4000sec. to 1/24 sec. 5.8K: 1/4000sec. to 1/24 sec. 5.4K: 1/4000sec. to 1/24 sec. 4.8K: 1/4000sec. to 1/24 sec. 4.6K(ANAMOR): 1/4000sec. to 1/24 sec. 4K/DCI4K: 1/4000sec. to 1/8 sec. FHD: 1/4000sec. to 1/8 sec. *Cannot choose slower shutter speed than framerate for some settings. | |
| Synchronized shutter speed for flash | Mechanical shutter: 1/125sec. or slower | |
| Continuous shooting | CH Electronic shutter Approx. 8.7fps (35mm Format Mode ON) (No. of recordable frames: JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 260 frames, Compressed RAW + JPEG 156 frames, Lossless compressed RAW + JPEG 148 frames, Uncompressed RAW + JPEG 71 frames) CH Electronic shutter Approx. 5.8fps (35mm Format Mode ON) (No. of recordable frames: JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 1000+ frames, Compressed RAW + JPEG 1000+ frames, Lossless compressed RAW + JPEG 1000+ frames, Uncompressed RAW + JPEG 1000+ frames) CH Electronic shutter Approx. 5.3fps (No. of recordable frames: JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 390 frames, Compressed RAW+JPEG 119 frames, Lossless compressed RAW+JPEG 119 frames, Uncompressed RAW+JPEG 98 frames) CH Mechanical shutter Approx. 8.0fps (No. of recordable frames: JPEG 1000+ frames, Compressed RAW 325 frames, Lossless compressed RAW 302 frames, Uncompressed RAW 76 frames, Compressed RAW+JPEG 75 frames, Lossless compressed RAW+JPEG 75 frames, Uncompressed RAW+JPEG 55 frames) CH Mechanical shutter Approx. 5.0fps (No. of recordable frames: JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 497 frames, Compressed RAW+JPEG 153 frames, Lossless compressed RAW+JPEG 152 frames, Uncompressed RAW+JPEG 116 frames) CL Mechanical shutter Approx. 2.0fps (No. of recordable frames: JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 1000+ frames, Compressed RAW+JPEG 1000+ frames, Lossless compressed RAW+JPEG 1000+ frames, Uncompressed RAW+JPEG 1000+ frames) *Electronic Front Curtain Shutter support CL only. *No. of recordable frames are calculated based on CFexpress Type B card in a cold start *Recordable frames depends on recording media *Speed of continuous shooting depends on shooting environment and shooting frames | |
| Drive Mode | AE Bracketing | 2 frames / 3 frames / 5 frames / 7 frames / 9 frames *by 1/3EV step, up to ±3EV steps |
| Filmsimulation bracketing | Any 3 types of film simulation selectable | |
| Dynamic Range Bracketing | 100% / 200% / 400% | |
| ISO sensitivity Bracketing | ±1/3EV / ±2/3EV / ±1EV | |
| White Balance Bracketing | ±1 / ±2 / ±3 | |
| Focus Bracketing | AUTO / MANUAL | |
| Multiple Exposure | Yes (Max. 9 frames) / Additive / Average / Bright / Dark | |
| Pixel Shift Multi Shot | HIGH RESOLUTION + ACCURATE COLOR: Yes ACCURATE COLOR: Yes | |
| Focus | Mode | Single AF / Continuous AF / MF |
| Type | Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF) | |
| Low-light Performance | Contrast: -2.5EV GF80mmF1.7 attached Phase Detection: -5.5EV GF80mmF1.7 attached | |
| AF frame selection | Single point AF: 13x9 / 25x17 (Changeable size of AF frame) Zone AF: 3x3 / 5x5 / 7x7 / Custom1-3 from 117 areas on 13×9 grid Wide/Tracking AF: Yes (AF-S: Wide / AF-C: Tracking) All: Yes | |
| Face/eye detection | Yes | |
| Subject detection | Yes (Animal/Bird/Automobile/Motorcycle&Bike/Airplane/Train) | |
| Flash | Shoe mount flash | Sync. Mode: 1st Curtain / 2nd Curtain / AUTO FP (HSS) Flash Mode: TTL (TTL AUTO / STANDARD / SLOW SYNC. ) / MANUAL / MULTI *When EF-X500 is set / OFF |
| Synchronized terminal | Sync. Mode: 1st Curtain / 2nd Curtain Flash Mode: MANUAL | |
| Hot shoe | Yes (Dedicated TTL Flash compatible) | |
| Viewfinder | EVF: 0.64 inch OLED Color Viewfinder, Approx. 9.44 million dots Coverage of Viewing Area vs. Capturing Area: Approx. 100% Eyepoint: Approx. 21mm (from the Rear End of the Camera's Eyepiece) Diopter Adjustment: -5?+2m-1 Magnification: 1.00x with 50mm Lens (35mm Equivalent) at infinity and Diopter set to -1.0m-1 Diagonal Angle of View: approx. 47° (Horizontal angle of view: approx. 38° ) Built-In Eye Sensor | |
| LCD monitor | 3.2 inch Tilt-Type(Three Direction) Touch Screen Color LCD Monitor Aspect Ratio: 4:3 Dots: Approx. 2.36 million dots | |
| Touch Screen Mode | Shooting Mode | AF, Focus Area, OFF, Double Tap Setting (ON/OFF), Touch Function Setting (ON/OFF), EVF Touch Screen Area Setting |
| Playback Mode | Swipe, Pinch-in / Pinch-out, Double-tap, Drag | |
| Sub LCD monitor | 2.09 inch Monochrome LCD Monitor Aspect Ratio: 4:3 Dots: 320x219-dot | |
| Movie recording | File format | MOV: Apple ProRes 422 HQ, Linear PCM (Stereo sound 24bit / 48KHz sampling) Apple ProRes 422, Linear PCM (Stereo sound 24bit / 48KHz sampling) Apple ProRes 422 LT, Linear PCM (Stereo sound 24bit / 48KHz sampling) HEVC/H.265, Linear PCM (Stereo sound 24bit / 48KHz sampling) MPEG-4 AVC/H.264, Linear PCM (Stereo sound 24bit / 48KHz sampling) MP4: MPEG-4 AVC/H.264, AAC |
| Movie compression | All Intra / Long GOP | |
| File size Frame rate Bitrate | [8K(17:9)] 8192 x 4320?24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [8K(16:9)] 7680 x 4320?29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [8K(2.76:1)] 8192 x 2968?24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [5.8K(2.35:1)] 5824 x 2476?29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [5.4K(17:9)] 5440 x 2868?29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [4.8K(3:2)] 4776 x 3184?24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [4.8K(16:9)] 4776 x 2688?29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [4.6K(1.38:1)] 4664 x 3380?24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [DCI4K(17:9)] 4096 x 2160?59.94p/50p/29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [4K(16:9)] 3840 x 2160?59.94p/50p/29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [Full HD(17:9)] 2048 x 1080?59.94p/50p/29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [Full HD(16:9)] 1920 x 1080?59.94p/50p/29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [Full HD(17:9) High speed rec.] 2048 x 1080?120p/100p?720Mbps (recording)/360Mbps (recording)/200Mbps (recording) [Full HD(16:9) High speed rec.] 1920 x 1080?120p/100p?720Mbps (recording)/360Mbps (recording)/200Mbps (recording) *Selectable mode will be changed depending on the "Image Format" setting. *For recording movies, use a CFexpress Type B card or SD memory card with UHS Speed Class 3 or higher. *For recording movies in 360Mbps, use a CFexpress Type B card or SD memory card with Video Speed Class 60 or higher. *For recording movies in 720Mbps, use a CFexpress Type B card or SD memory card with Video Speed Class 90 or higher. *Selectable bitrate will be changed depends on the setting. *Apple ProRes codec can be only recorded to CFexpress Type B card *Bitrate for Apple ProRes codec is not selectable. *Recording time can become short depending on the temperature and/or shooting conditions | |
| Film simulation mode | 20 modes (PROVIA/Standard, Velvia/Vivid, ASTIA/Soft, Classic Chrome, REALA ACE, PRO Neg.Hi, PRO Neg.Std, Classic Neg., Nostalgic Neg., ETERNA/Cinema, ETERNA BLEACH BYPASS, ACROS, ACROS + Ye Filter, ACROS + R Filter, ACROS + G Filter, Black & White, Black & White + Ye Filter, Black & White + R Filter, Black & White + G Filter, Sepia) | |
| Monochromatic Color | Yes | |
| Grain Effect | Roughness | STRONG, WEAK, OFF |
| Size | LARGE, SMALL | |
| Color Chrome Effect | STRONG, WEAK, OFF | |
| Color chrome Blue | STRONG, WEAK, OFF | |
| Smooth Skin Effect | STRONG, WEAK, OFF | |
| Dynamic range setting | Still | AUTO / 100? / 200? / 400? ISO restriction: DR100%: No limit?DR200%: ISO160 or more?DR400%: ISO320 or more |
| Movie | 100? / 200? / 400? ISO restriction: DR100%: No limit?DR200%: ISO200 or more?DR400%: ISO400 or more | |
| White balance | Auto | White Priority / Auto / Ambience Priority |
| Custom | Custom1 - 3 | |
| Color temperature selection | 2500K?10000K | |
| Preset | Daylight / Shade / Fluorescent Light-1 / Fluorescent Light-2 / Fluorescent Light-3 / Incandescent Light / Underwater | |
| Clarity setting | ±5 steps | |
| Self-timer | Still | 10sec. / 2sec. |
| Movie | 10sec. / 5sec. / 3sec. | |
| Interval timer shooting | Yes (Setting : Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing, Interval priority mode) | |
| Wireless transmitter | Standard | IEEE802.11a/b/g/n/ac (standard wireless protocol) |
| Encryption | WPA/WPA2 mixed mode, WPA3 | |
| Access mode | Infrastructure | |
| Bluetooth® | Standartd | Bluetooth Ver. 4.2 (Bluetooth low energy) |
| Operating frequency (Center frequency) | 2402?2480MHz | |
| Terminal | Digital interface | USB Type-C (USB3.2 Gen2x1) |
| HDMI output | HDMI connector (Type A) | |
| LAN Terminal | 1000BASE-T?100BASE-TX?10BASE-T | |
| Others | ø3.5mm, stereo mini connector (Microphone and Remote Release) ø3.5mm, stereo mini connector (Headphone) Hot shoe Synchronized terninal | |
| Power supply | NP-W235 Li-ion battery (included) | |
| Battery life for still images*2 | Normal Mode: Approx. 540 frames *Auto power save ON *When GF63mmF2.8 R WR is set | |
| Actual battery life of movie capture*2 | 8K: Approx. 60min. (29.97p) 4K: Approx. 60min. (59.94p) Full HD: Approx. 80min. (59.94p) *Face detection is set to OFF | |
| Continuance battery life of movie capture*2 | 8K: Approx. 80min. (29.97p) 4K: Approx. 90min. (59.94p) Full HD: Approx. 140min. (59.94p) *Face detection is set to OFF | |
| Dimensions | Width: 152.4mm Height: 117.4mm Depth: 98.6mm (Minimum Depth: 46.5mm) | |
| Excluding EVF | Width: 152.4mm Height: 103.5mm Depth: 73.5mm (Minimum Depth: 46.5mm) | |
| Weight | including battery and memory card: Approx. 948g (including EVF: 1,030g) excluding battery and memory card: Approx. 867g (including EVF: 949g) | |
| Operation Environment | Operating Temperature | -10??+40? |
| Operating Humidity | 10% - 80% (no condensation) | |
| Accessories included | Interchangeable electronic viewfinder EVF-GFX3 Li-ion battery NP-W235 AC power adapter AC-5VJ Plug adapter USB cable Shoulder strap Body cap Hot shoe cover Vertical battery grip connector cover Memory card slot cover Sync terminal cover Cooling fan connector cover Cable protector | |
| Resolution/Aspect | Size | Frame rate | File format/Compression | Bit rate*2 | Bit depth | HDMI outupt Resolution(Frame rate)/Sampling/Bit depth | Crop Magnification | ||
|---|---|---|---|---|---|---|---|---|---|
| DIS ON | DIS OFF | ||||||||
| 8K 16:9 | 7680 x 4320 | 29.97p 25.00p 24.00p 23.98p | ProRes 422 HQ MOV*1 | 3520Mbps(29.97p)*3 | 10bit | FHD 4:2:2 10bit*4 | - | 1.51x | |
| ProRes 422 MOV*1 | 2352Mbps(29.97p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 1632Mbps(29.97p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | FHD 4:2:2 10bit (H.265 All-Intra 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 All-Intra 4:2:0 MOV)*4 | - | 1.51x | |||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | FHD 4:2:2 10bit (H.265 Long GOP 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 Long GOP 4:2:0 MOV)*4 | - | 1.51x | |||||
| DCI8K 17:9 | 8192 x 4320 | 24.00p 23.98p | ProRes 422 HQ MOV*1 | 3004Mbps(24.00p)*3 | 10bit | FHD 4:2:2 10bit*4 | - | 1.42x | |
| ProRes 422 MOV*1 | 2007Mbps(24.00p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 1393Mbps(24.00p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | FHD 4:2:2 10bit (H.265 All-Intra 4:2:2 MOV)*4 DCI4K 4:2:2 10bit (H.265 All-Intra 4:2:0 MOV)*4 | - | 1.42x | |||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | FHD 4:2:2 10bit (H.265 Long GOP 4:2:2 MOV)*4 DCI4K 4:2:2 10bit (H.265 Long GOP 4:2:0 MOV)*4 | - | 1.42x | |||||
| ANAMOR 8K 2.76:1 | 8192 x 2968 | 24.00p 23.98p | ProRes 422 HQ MOV*1 | 2064Mbps(24.00p)*3 | 10bit | FHD 4:2:2 10bit*4 | - | 1.24x | |
| ProRes 422 MOV*1 | 1379Mbps(24.00p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 957Mbps(24.00p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | FHD 4:2:2 10bit (H.265 All-Intra 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 All-Intra 4:2:0 MOV)*4 | - | 1.24x | |||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | FHD 4:2:2 10bit (H.265 Long GOP 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 Long GOP 4:2:0 MOV)*4 | - | 1.24x | |||||
| CINE 5.8K 2.35:1 | 5824 x 2476 | 29.97p 25.00p 24.00p 23.98p | ProRes 422 HQ MOV*1 | 1530Mbps(29.97p)*3 | 10bit | FHD 4:2:2 10bit*4 | - | 1.0x | |
| ProRes 422 MOV*1 | 1022Mbps(29.97p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 709Mbps(29.97p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | FHD 4:2:2 10bit (H.265 All-Intra 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 All-Intra 4:2:0 MOV)*4 | - | 1.0x | |||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | FHD 4:2:2 10bit (H.265 Long GOP 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 Long GOP 4:2:0 MOV)*4 | - | 1.0x | |||||
| 5.4K 17:9 | 5440 x 2868 | 29.97p 25.00p 24.00p 23.98p | ProRes 422 HQ MOV*1 | 1655Mbps(29.97p)*3 | 10bit | FHD 4:2:2 10bit*4 | - | 1.07x | |
| ProRes 422 MOV*1 | 1106Mbps(29.97p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 767Mbps(29.97p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | FHD 4:2:2 10bit (H.265 All-Intra 4:2:2 MOV)*4 DCI4K 4:2:2 10bit (H.265 All-Intra 4:2:0 MOV)*4 | - | 1.07x | |||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | FHD 4:2:2 10bit (H.265 Long GOP 4:2:2 MOV)*4 DCI4K 4:2:2 10bit (H.265 Long GOP 4:2:0 MOV)*4 | - | 1.07x | |||||
| 4.8K 3:2 | 4776 x 3184 | 24.00p 23.98p | ProRes 422 HQ MOV*1 | 1291Mbps(24.00p)*3 | 10bit | FHD 4:2:2 10bit*4 | - | 1.21x | |
| ProRes 422 MOV*1 | 862Mbps(24.00p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 598Mbps(24.00p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | FHD 4:2:2 10bit (H.265 All-Intra 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 All-Intra 4:2:0 MOV)*4 | - | 1.21x | |||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | FHD 4:2:2 10bit (H.265 Long GOP 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 Long GOP 4:2:0 MOV)*4 | - | 1.21x | |||||
| 4.8K 16:9 | 4776 x 2688 | 29.97p 25.00p 24.00p 23.98p | ProRes 422 HQ MOV*1 | 1362Mbps(29.97p)*3 | 10bit | FHD 4:2:2 10bit*4 | - | 1.21x | |
| ProRes 422 MOV*1 | 910Mbps(29.97p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 631Mbps(29.97p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | FHD 4:2:2 10bit (H.265 All-Intra 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 All-Intra 4:2:0 MOV)*4 | - | 1.21x | |||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | FHD 4:2:2 10bit (H.265 Long GOP 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 Long GOP 4:2:0 MOV)*4 | - | 1.21x | |||||
| ANAMOR 4.6K 1.38:1 | 4664 x 3380 | 24.00p 23.98p | ProRes 422 HQ MOV*1 | 1338Mbps(24.00p)*3 | 10bit | FHD 4:2:2 10bit*4 | - | 1.24x | |
| ProRes 422 MOV*1 | 894Mbps(24.00p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 620Mbps(24.00p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | FHD 4:2:2 10bit (H.265 All-Intra 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 All-Intra 4:2:0 MOV)*4 | - | 1.24x | |||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | FHD 4:2:2 10bit (H.265 Long GOP 4:2:2 MOV)*4 4K 4:2:2 10bit (H.265 Long GOP 4:2:0 MOV)*4 | - | 1.24x | |||||
| DCI4K 17:9 4K 16:9 | 4096 x 2160 3840 x 2160 | 59.94p 50.00p 29.97p 25.00p 24.00p 23.98p | ProRes 422 HQ MOV*1 | 1877Mbps(59.94p)*3 | 10bit | DCI4K/4K 4:2:2 10bit | - | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | |
| ProRes 422 MOV*1 | 1254Mbps(59.94p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 870Mbps(59.94p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||||||
| H.264 All-Intra 4:2:0 MOV | 360Mbps | 8bit | DCI4K/4K 4:2:2 8bit | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||||
| H.264 Long GOP 4:2:0 MOV H.264 Long GOP 4:2:0 MP4 | 360Mbps 200Mbps 100Mbps 50Mbps | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||||||
| FHD 17:9 16:9 | 2048 x 1080 1920 x 1080 | 59.94p 50.00p 29.97p 25.00p 24.00p 23.98p | ProRes 422 HQ MOV*1 | 469Mbps(FHD16:9 59.94p)*3 | 10bit | FHD 4:2:2 10bit*5 | - | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | |
| ProRes 422 MOV*1 | 314Mbps(FHD16:9 59.94p)*3 | ||||||||
| ProRes 422 LT MOV*1 | 218Mbps(FHD16:9 59.94p)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps 360Mbps | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps 360Mbps 200Mbps 100Mbps 50Mbps | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||||||
| H.264 All-Intra 4:2:0 MOV | 360Mbps | 8bit | FHD 4:2:2 8bit*5 | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||||
| H.264 Long GOP 4:2:0 MOV H.264 Long GOP 4:2:0 MP4 | 360Mbps 200Mbps 100Mbps 50Mbps | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||||||
| High speed FHD 17:9 FHD 16:9 | 2048 x 1080 1920 x 1080 | 120p (2x/4x/5x) 100p (2x/4x) | ProRes 422 HQ MOV*1 | 880Mbps(FHD16:9 120p recording)*3 | 10bit | FHD(59.94p) 4:2:2 10bit*6 | - | GF:1.0x Premista:1.08x | |
| ProRes 422 MOV*1 | 588Mbps(FHD16:9 120p recording)*3 | ||||||||
| ProRes 422 LT MOV*1 | 408Mbps(FHD16:9 120p recording)*3 | ||||||||
| H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV | 720Mbps (when recording) 360Mbps (when recording) | ||||||||
| H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV | 720Mbps (when recording) 360Mbps (when recording) 200Mbps (when recording) | ||||||||
| H.264 All-Intra 4:2:0 MOV | 360Mbps (when recording) | 8bit | FHD(59.94p) 4:2:2 8bit*6 | ||||||
| H.264 Long GOP 4:2:0 MOV H.264 Long GOP 4:2:0 MP4 | 360Mbps (when recording) 200Mbps (when recording) | ||||||||
| Resolution/Aspect | Size | Frame rate | HDMI outupt Resolution/Sampling/Bit depth | Crop Magnification | |||
|---|---|---|---|---|---|---|---|
| DIS ON | DIS OFF | ||||||
| 8K 16:9 | 7680 x 4320 | 29.97p 25.00p 24.00p 23.98p | 8K 4:2:2 10bit | - | 1.51x | ||
| DCI8K 17:9 | 8192 x 4320 | 24.00p 23.98p | 8K 4:2:2 10bit*4 | - | 1.42x | ||
| ANAMOR 8K 2.76:1 | 8192 x 2968 | 24.00p 23.98p | FHD 4:2:2 10bit*4 | - | 1.24x | ||
| CINE 5.8K 2.35:1 | 5824 x 2476 | 29.97p 25.00p 24.00p 23.98p | 4K 4:2:2 10bit*4 | - | 1.0x | ||
| 5.4K 17:9 | 5440 x 2868 | 29.97p 25.00p 24.00p 23.98p | DCI4K 4:2:2 10bit*4 | - | 1.07x | ||
| 4.8K 3:2 | 4776 x 3184 | 24.00p 23.98p | 4K 4:2:2 10bit*4 | - | 1.21x | ||
| 4.8K 16:9 | 4776 x 2688 | 29.97p 25.00p 24.00p 23.98p | 4K 4:2:2 10bit*4 | - | 1.21x | ||
| ANAMOR 4.6K 1.38:1 | 4664 x 3380 | 24.00p 23.98p | 4K 4:2:2 10bit*4 | - | 1.24x | ||
| DCI4K 17:9 4K 16:9 | 4096 x 2160 3840 x 2160 | 59.94p 50.00p 29.97p 25.00p 24.00p 23.98p | DCI4K/4K 4:2:2 10bit | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||
| FHD 17:9 16:9 | 2048 x 1080 1920 x 1080 | 59.94p 50.00p 29.97p 25.00p 24.00p 23.98p | FHD 4:2:2 10bit*5 | 1.1x | GF:1.0x Premista:1.08x 35mm/ANAMORPHIC(35mm):1.21x | ||
| Resolution/Aspect | Size | Frame rate | HDMI outupt Resolution(Frame rate)/Sampling/Bit depth | Crop Magnification | |||
|---|---|---|---|---|---|---|---|
| DIS ON | DIS OFF | ||||||
| FHD 16:9 | 1920 x 1080 | 120p 100p | FHD(120p/100p) 4:2:2 10bit | - | GF:1.0x Premista:1.08x | ||
| Resolution/Aspect | Size | Frame rate | Crop Magnification | ||
|---|---|---|---|---|---|
| DIS ON | DIS OFF | ||||
| 8K 16:9 | 7680 x 4320 | 29.97p 25.00p 24.00p 23.98p | - | 1.51x | |
| DCI8K 17:9 | 8192 x 4320 | 24.00p 23.98p | - | 1.42x | |
| 4K 16:9 | 3840 x 2160 | 59.94p 50.00p 29.97p 25.00p 24.00p 23.98p | - | GF:1.0x | |
_1.jpg)
